| CPM-132 ST6 – Specification | Value |
|---|---|
| Warranty | 2 years |
| Voltage | 230 Volt |
| Speed | 2900 rpm |
| Power | 550 Watt |
| Head (Min–Max) | 12–22.5 m |
| Flow rate at specified heads | 20–120 liters/min |
| Suction connection | 1 inch |
| Discharge connection | 1 inch |
| Maximum suction depth | 7 meters |
| Max liquid temperature | 90 °C |
| Max ambient temperature | 40 °C |
| Installation length | 257 mm |
| Pump housing | Cast iron with threaded ISO 228/1 |
| Shaft | Stainless steel EN 10088-3-1.4104 |
| Mechanical seal | AR-12 Ceramic-Graphite-NBR |
| Impeller | Stainless steel AISI 304 |
| Cable length | 0 meters |
| Protection class | IP X4 |
| Insulation class | F |
| Best efficiency flow rate | 90 liters/min at 17.5 meters |
| Weight | 8.4 kg |
Category : Sea water pump
Pedrollo CPm 132 ST6 – 1Ph Centrifugal Pump
This pump is suitable for circulating fresh water in MBC Marine chiller systems. It is designed for clean liquids that are non-aggressive to pump materials. Reliable and easy to use, it must be installed in a dry, protected location.
