MP20-R Sea Water Pump
MP20-R Sea Water Pump
MP20-R Sea Water Pump
MP20-R Sea Water Pump

MP20-R Sea Water Pump

Specification Value
Model MBC MP-20R (220V)
Pump Type Magnetic-drive centrifugal (sealless)
Rated Voltage 220 V AC
Motor Power ~20 W
Speed ~3100 rpm
Maximum Flow Rate ~27 L/min
Maximum Head ~2.5 m
Current Draw ~0.22–0.25 A
Construction Material Glass fiber reinforced polypropylene (GFR-PP)
Shaft Ceramic
Bearings PTFE (Teflon)
Impeller GFR-PP, closed design
Sealing Sealless (magnetic coupling)
Inlet/Outlet Connection 20 mm hose barb
Enclosure Totally Enclosed Non-Ventilated (TENV)
Max Fluid Specific Gravity ~1.1 kg/L
Insulation Class Class E or higher
Operating Mode Continuous
Noise Level Low (quiet operation)
Weight 1.8 kg

Category :

Description

The MBC MD-20R is a compact, magnetically coupled centrifugal pump designed for continuous-duty circulation in marine and technical environments. Its sealless construction eliminates the risk of leakage, making it ideal for closed-loop chilled water systems.
Equipped with a 220 V motor, ceramic shaft, and chemically resistant polypropylene housing, the MD-20R provides a flow rate of up to 31 L/min with a maximum head of 2.5 meters—well suited for 230 V-based air conditioning systems on board.
The 20 mm hose connection ensures compatibility with standard marine plumbing, while the quiet and energy-efficient operation supports long-term use with minimal maintenance.
