DC 5624F 24V Specification Value
Rated Voltage 24 V DC
Power Consumption 42–54 W
Rated Current ~1.4–2.2 A
Maximum Head Up to 16 m
Maximum Flow Rate Up to 2400 L/h (40 L/min)
Waterproof Rating IP68
Expected Lifetime >30,000 hours
Noise Level ≤35–40 dB
Pump Housing Material PPS with 30% glass fiber
Shaft Ceramic shaft
Sealing Type Magnetic isolation (no seal)
Impeller Closed impeller
Insulation Class H (180 °C)
Inlet/Outlet 20 mm threaded
Operating Voltage Range 12–30 V DC
Operating Temperature Range –30 °C to +100 °C
Protection Features Dry-run, overload, reverse polarity, lock protection
Speed Control Not available
Weight ~520 g
Dimensions 102 × 78 × 80 mm

Categories : ,

Description

The MBC Marine DC55F circulation pump is a reliable, brushless, magnetically isolated centrifugal pump designed for MBC Marine’s 24V DC air conditioning units, offering strong performance even in demanding marine environments.

With a maximum head of up to 16 meters and a flow rate of up to 2400 liters per hour (40 L/min), it is well-suited for installations with longer piping or elevated condenser positions.

Its IP68 waterproof construction allows for both submerged and dry installation, while the ceramic shaft and durable composite housing ensure a long, maintenance-free service life of up to 30,000 hours.

The MBC Marine DC55F 24V model is a perfect match for MBC Marine’s 24V systems in the 7000–12000 BTU range, where consistent water circulation and quiet, dependable operation are essential.
