| DC5612E / 12V Specification | Value |
|---|---|
| Rated Voltage | 12 V DC |
| Power Consumption | ~42 W |
| Max Current | ~3.5 A |
| Max Head | Up to 10 meters |
| Max Flow Rate | Up to 1800 L/h (30 L/min) |
| Waterproof Rating | IP68 |
| Lifetime | >30,000 hours |
| Noise Level | ≤35 dB |
| Pump Housing | PPS with 30% glass fiber |
| Shaft Type | Ceramic shaft, magnetically isolated |
| Sealing | No mechanical seal (magnetic isolation) |
| Impeller Type | Closed impeller |
| Protection Features | Dry-run, overload, reverse polarity, lock |
| Speed Control Options | PWM / 0–5 V analog / potentiometer |
| Suitable Media | Water, oil, mild acid/alkaline (pre-test) |
| Operating Temp Range | -30 °C to +100 °C (with correct driver) |
| Weight | ~0.52 kg |
| Dimensions | ~100 × 75 × 60 mm (approx., model dependent) |
Categories : Accessories, Sea water pump
The DC5612E brushless, magnetically isolated centrifugal pump is an excellent match for MBC Marine’s 12V DC air conditioning systems. It delivers reliable, quiet (<35 dB), and energy-efficient operation even under demanding conditions.
With its IP68-rated waterproof design, the pump can be installed either submerged or in a dry setup. Its durable ceramic shaft ensures a long, maintenance-free service life of up to 30,000 hours.
The DC5612E can provide up to 10 meters of head and a flow rate of 30 liters per minute in a 12V system, making it a perfect choice for MBC Marine’s 7000 BTU DC air conditioners—especially in installations with longer pipe runs or elevated condenser positions.
