DC60E 24V Specification | Value |
---|---|
Model | DC60E |
Rated Voltage | 24 V DC |
Power Consumption | 108–120 W |
Rated Current | ~4.5–5 A |
Maximum Head | Up to 12 m |
Maximum Flow Rate | Up to 3800 L/h (≈63 L/min) |
Waterproof Rating | IP68 |
Expected Lifetime | ≥30,000 hours |
Noise Level | ≤40 dB |
Pump Housing Material | PPS with 30% glass fiber |
Shaft | Ceramic |
Impeller Type | Closed impeller |
Sealing Type | Magnetic isolation |
Insulation Class | H (180 °C) |
Inlet/Outlet Size | 20 mm threaded (½″) |
Operating Voltage Range | 10–30 V DC |
Operating Temperature Range | –30 °C to +100 °C |
Protection Features | Dry-run, jam, overload, reverse polarity |
Speed Control | Not available |
Weight | ~0.89 kg |
Dimensions | 152 × 88 × 110 mm |
Categories : Accessories, Sea water pump
The MBC Marine DC60G is a powerful and reliable brushless centrifugal pump, ideally suited for MBC Marine’s 24V DC air conditioning systems with higher water circulation demands.
With a maximum head of up to 12 meters and a flow rate of up to 63 liters per minute, it is an excellent choice for larger or more complex installations, including systems with multiple air handlers or extended piping runs.
Its IP68-rated waterproof construction allows for both submerged and dry-mounted installation. The ceramic shaft and reinforced housing provide long-lasting, maintenance-free operation with a rated lifespan exceeding 30,000 hours.
This model is fully compatible with MBC Marine’s 24V systems up to 48,000 BTU combined capacity, making it the ideal solution for multi-zone setups where efficient and consistent freshwater circulation is critical.
