Capacity (BTU/h): 24 000 BTU/h
SMART CONNECT COMPATIBLE · with optional Smart Touch controller
| Voltage / Frequency 230V / 50-60Hz |
Operation Mode Cooling / Heating |
| Warranty 2-year |
Evaporator Material Copper Fin – copper tubes, coated copper fins |
| Basic package includes: | LED Display, 5m Network cable, Mounting brackets, Insulation tape |
| Possible optionals: | Soft Starter Smart Touch controller – touch screen + Wi-Fi for Smart Connect app control |
| Unit Dimensions (mm) H x W x D |
Condenser: 408x250x330 Evaporator: 430x560x370 |
| Package Dimensions (mm) H x W x D |
|
| UNIT Weight (kg) | Condenser: 52 kg Evaporator: 18 kg |
| Shipping Weight (kg) |
Categories : AC UNITS, SCP - SPLIT Systems
SKU : N/A
With 24,000 BTU/h capacity, the SCP 24K is ideal for large cabins or saloons. It delivers strong cooling and heating performance while keeping the compressor noise out of the living area—quiet, efficient, and built for marine use.
Its Copper Fin evaporator – copper tubes with coated copper fins – ensures efficient heat transfer and long-lasting corrosion resistance in the marine environment.
Optional · Smart Connect
Add the Smart Touch controller and connect this unit to MBC Marine Smart Connect: set temperature and mode remotely, receive fault notifications, give charter guests access to their own cabin and get remote support from your dealer. Learn more about Smart Connect →
App coming soon
Unit Parameters | SCP 24 | ||||
|---|---|---|---|---|---|
Parameter list of Condensing unit | |||||
Cooling capacity | Btu/h | 24000 | |||
Heating capacity | Btu/h | 26400 | |||
Power Source | 230 V / 50Hz | ||||
Input power (kW) | 1.36 | ||||
Refrigerant | R410A | ||||
Dimension of Condensing unit | Height | 408 | |||
Weight | 250 | ||||
Depth | 330 | ||||
Connection Pipe | Gas | 12.7 | |||
Liquid |
9.52 | ||||
Sea Water Connection Size | 1″ | ||||
Drain Connection Size | DN20 | ||||
Net Weight (kg) | 58 | ||||
Parameter list of Evaporator unit | |||||
Dimension of Evaporator unit | Height | 430 | |||
Width | 560 | ||||
Depth | 370 | ||||
Minimum Air Duct Size (mm) | 200 | ||||
Input power (W) | 300 | ||||
Connection Pipe | Gas | 12.7 | |||
Liquid | 9.52 | ||||
Drain Connection Size | DN20 | ||||
Net Weight (kg) | 18 | ||||
Smart Connect compatible
With the optional Smart Touch controller, this unit connects to MBC Marine Smart Connect: remote control from your smartphone, fault notifications, Guest Mode for charter guests and remote support from your dealer.
App coming soon
Hungarian manufacturer of marine air conditioning systems since 2010 – built in the EU, backed by our own warehouse stock and a trained partner network.
