Capacity (BTU/h): 16 000 BTU/h
SMART CONNECT COMPATIBLE · with optional Smart Touch controller
| Voltage / Frequency 230V / 50-60Hz |
Operation Mode Cooling / Heating |
| Warranty 2-year |
Evaporator Material Copper Fin – copper tubes, coated copper fins |
| Basic package includes: | LED Display, 5m Network cable, Mounting brackets, Insulation tape |
| Possible optionals: | Soft Starter Smart Touch controller – touch screen + Wi-Fi for Smart Connect app control |
| Unit Dimensions (mm) H x W x D |
Condenser: 365x250x330 Evaporator: 355x400x320 |
| Package Dimensions (mm) H x W x D |
|
| UNIT Weight (kg) | Condenser: 32 kg Evaporator: 14 kg |
| Shipping Weight (kg) |
Categories : AC UNITS, SCP - SPLIT Systems
SKU : N/A
SCP 16K Split Marine Air Conditioner – Efficient Comfort for Larger Cabins
The SCP 16K provides 16,000 BTU/h of cooling and heating—perfect for larger cabins or multi-zone layouts. Its split design keeps the noise outside, ensuring silent comfort and space-saving installation in marine environments.
Its Copper Fin evaporator – copper tubes with coated copper fins – ensures efficient heat transfer and long-lasting corrosion resistance in the marine environment.
Optional · Smart Connect
Add the Smart Touch controller and connect this unit to MBC Marine Smart Connect: set temperature and mode remotely, receive fault notifications, give charter guests access to their own cabin and get remote support from your dealer. Learn more about Smart Connect →
App coming soon
Unit Parameters | SCP 16 | ||||
|---|---|---|---|---|---|
Parameter list of Condensing unit | |||||
Cooling capacity | Btu/h | 16000 | |||
Heating capacity | Btu/h | 17600 | |||
Power Source | 230 V / 50Hz | ||||
Input power (kW) | 1.15 | ||||
Refrigerant | R410A | ||||
Dimension of Condensing unit | Height | 365 | |||
Width | 330 | ||||
Depth | 250 | ||||
Connection Pipe | Gas | 12.7 | |||
Liquid |
9.52 | ||||
Sea Water Connection Size | 1/2″ | ||||
Drain Connection Size | DN20 | ||||
Net Weight (kg) | 32 | ||||
Parameter list of Evaporator unit | |||||
Dimension of Evaporator unit | Height | 355 | |||
Width | 400 | ||||
Depth | 320 | ||||
Minimum Air Duct Size (mm) | 150 | ||||
Input power (W) | 200 | ||||
Connection Pipe | Gas | 12.7 | |||
Liquid | 9.52 | ||||
Drain Connection Size | DN20 | ||||
Net Weight (kg) | 14 | ||||
Smart Connect compatible
With the optional Smart Touch controller, this unit connects to MBC Marine Smart Connect: remote control from your smartphone, fault notifications, Guest Mode for charter guests and remote support from your dealer.
App coming soon
Hungarian manufacturer of marine air conditioning systems since 2010 – built in the EU, backed by our own warehouse stock and a trained partner network.
